MODS-G-8P8C-G Single Port RJ45 Modular Jack Cat5 Connector LPJE8015NNL
| 1X1 RJ11 4P4C Connector without Integrated Magnetics, Without LED, RoHS |
| LINK-PP Part Number | LPJE8015NNL |
| Part Number | MODS-G-8P8C-G |
| Application-Lan | ETHERNET(NoN PoE) |
| Contact Mating Area Plating | GOLD 1.5u"/3u"/6u"/15u"/30u"/50u" |
| Cores per Port | Without Integrated Magnetics |
| Diodes | NO DIODES |
| LED Option | Without LED |
| Latch | TAB UP |
| Number of Ports | 1X1 |
| PCB Mount Angle | SIDE ENTRY |
| Package Height (mm) | 14.50 |
| Package Length (mm) | 13.00 |
| Package Width (mm) | 10.00 |
| Pin Type | THT SOLDER |
| RoHS Compliant | YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION |
| Search | YES |
| Shield EMI Tabs | Without |
| Speed | WITHOUT MAGNETICS |
| Storage | -40 TO +85℃ |
| Operation | -40 TO + 85℃ |
| Turns Ratio RX | 1CT:1CT |
| Turns Ratio TX | 1CT:1CT |
